　Optical System

　Infinite Optical System

　Viewing Head

　Trinocular Head Inclined at 30°，Interpupillary 48-75mm

　Eyepiece

　High-point, Extra Wide Field Eyepiece EW10X/ 22

　Nosepiece

　Quintuple Nosepiece

　Objective

　LWD Infinite Plan Objective

 　4X/0.1, WD18mm

 　10X/0.25, WD10mm

 　20X/0.4, WD5.1mm

　 40X/0.6, WD2.6mm

　Infinite Plan Phase Objective

　 PH 10X/0.25, WD10mm

 　PH 20X/0.4, WD5.1mm

 　PH 40X/0.6, WD0.35mm

　Infinite Plan Fluorescent Objective

 　4X, 10X, 20X, 40X

　Condenser

　ELWD Condenser NA 0.3, LWD 72mm

　Focusing

　Coaxial Coarse and Fine Adjustment, Vertical Objective Movement, Coarse Stroke 37.7mm per rotation, Fine Stroke 0.2mm per rotation

　Stage

　Plain stage 160X250 mm, Attachable Mechanical Stage 80X120mm

　Illumination

　Halogen Lamp 6V/ 30W

　Filter

　Blue/Green and Ground Glass (ф45mm)

　Phase Annulus

　Centering telescope

　Photo Attachment

　Video Adapter

　Video Adapter with C Mount

　Reflected Light Source

Excitation

Dichroic Mirror

Barrier Filter

　Blue excitation

BP460～490

DM500

BA520

　Blue excitation(B1)

BP460～495

DM505

BA510～550

　Green excitation

BP480～550

DM570

BA590

　Ultraviolet excitation

BP330～385

DM400

BA420

　Violet excitation

BP400～410

DM455

BA455

　Lamp

　100W HBO Ultra Hi-voltage Spherical Mercury Lamp

　Protection barrier

　Barrier to Resist the Ultraviolet Light

　Power Supplier

　Power Supplier NFP-1, Wide range of voltage 100-240V, Digital Display

　Immersion Oil

　Fluorescent Free Oil

　Neutral ND25/ ND6 Filter

　Centering Plate
