Excellent image quality with optical system.
Comfortable operating with ergonomic structure.
Better illumination, convenient replacement of attachment with sliding-in centerable condenser.
| Optical System |
Infinite Optical System |
| Viewing Head |
Seidentopf Binocular Viewing Head, 30° Inclined, Interpupillary 48-75mm |
|
Seidentopf Trinocular Viewing Head, 30° Inclined, Interpupillary 48-75mm |
|
| Eyepiece |
Wide Field Eyepiece WF 10X/18 |
|
Extra Wide Field Eyepiece EW10X/20 with Diopter Adjustment |
|
| Objective |
Infinitive Semi-plan Achromatic Objectives 4X,10X,40X,100X |
|
Infinitive Plan Achromatic Objectives 4X,10X,40X,100X |
|
| Nosepiece |
Quadruple Nosepiece |
| Stage |
Double Layers Mechanical Stage 140mmX140mm/ 75mmX50mm |
| Condenser |
Sliding-in Centerable condenser NA1.25 |
| Focusing System |
Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Coarse Stroke 37.7mm per Rotation, Fine Stroke 0.2mm per Rotation, Moving Range 20mm |
| Illumination |
S-LED Illumination, Brightness Adjustable |
|
6V/ 20W Halogen Lamp, Brightness Adjustable |
|
| Phase Contrast Kit |
|
|
Fluorescent Attachment |
YX-2 Epi-fluorescent Attachment |
|
FL-LED Epi-fluorescent Attachment |
|
| Dark Field Attachment |
|
| Temperature Control System |
5W LED Illumination, Temperature controlling range: Room temperature to 50℃ |
